12MP IP 360 Fisheye Camera |
 |
Low Light - 0.03 Lux |
 |
Built-In Mic |
Introducing the Illumivue IP12VD360-IR 12MP 360 Fisheye IP Camera, a state-of-the-art surveillance solution that offers panoramic coverage and exceptional image quality. With its advanced technology and versatile design, this camera provides comprehensive security for a wide range of applications.
The IP12VD360-IR boasts a 360-degree fisheye lens, allowing for a panoramic view of your surroundings. With its wide-angle coverage, this camera eliminates blind spots, providing you with a complete and immersive surveillance experience. Monitor an entire room, hallway, or outdoor area without the need for multiple cameras, simplifying your surveillance setup.
Designed with a compact and discrete form factor, the IP5VD360-IR seamlessly blends into any environment. Its unobtrusive design makes it ideal for installations where aesthetics are important. Enjoy comprehensive surveillance without compromising the visual appeal of your space.
With advanced motion detection and intelligent alerts, this camera keeps you informed of any suspicious activity in real-time. Receive instant notifications directly to your smartphone or computer, enabling you to take immediate action when necessary. Additionally, the camera supports remote viewing, allowing you to access live or recorded footage from anywhere in the world through a user-friendly mobile app or web browser interface.
The Illumivue IP12VD360-IR 12MP 360 Fisheye IP Camera is a versatile and powerful security solution. With exceptional image quality, panoramic coverage, enhanced night vision capabilities, and intelligent alerts, this camera provides comprehensive surveillance coverage for a wide range of applications. Invest in the IP12VD360-IR today and experience enhanced visual clarity, comprehensive coverage, and peace of mind for your security needs.
- De-warping is available on the Illumivue App/PC Software OR on a local monitor when using an NVR16.2 or higher
- 12MP 360° Fisheye IP camera
- 1.8mm @ F2.0 Lens
- 360° field of view
- 120dB true WDR technology enables clear image in strong light scene
- Low Light - 0.03 Lux
- 49ft (15m) Smart IR Range
- Ultra 265, H.265, H.264, MJPEG
- Built-in Mic x 2, Supports the detection of sounds over longer distances
- Alarm:1 in/1 out, Audio: 1 in/1 out
- Supports 256 G Micro SD card
- Support PoE power supply
- Onvif Support (Profile S, Profile G, Profile T)
- IK10 vandal resistant
- IP66 protection
- NDAA-Compliant
Download the Illumivue Apps
Access, Set-up, and Manage Illumivue surveillance products through your network via iOS, Android or Windows.
| Camera | |||||
| Sensor | 1/1.7", progressive scan, 12.0 megapixel, CMOS | ||||
| Lens | 1.8mm@F2.0 | ||||
| Angle of View | 360° | ||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
|---|---|---|---|---|---|
| 1.8 | 43.8 | 17.5 | 8.8 | 4.4 | |
| Minimum Illumination | Color: 0.03 Lux (F2.0, AGC ON) 0 Lux with IR |
||||
| IR Range | Up to 15m (49ft) IR range | ||||
| IR On/Off Control | Auto/Manual | ||||
| WDR | DWDR | ||||
| Edge Storage | Micro SD, up to 256 GB | ||||
| Built-in Mic | Supported 2 | ||||
| Built-in Speaker | Yes | ||||
| Video | |||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | ||||
| Video Bit Rate | 128 Kbps ~ 16 Mbps | ||||
| Image | |||||
| Digital Noise Reduction | 2D/3D DNR | ||||
| Smart Illumination | Supported | ||||
| Dewarping | N/A | ||||
| Flip | Normal/Flip Vertical/ Flip Horizontal/180° | ||||
| General | |||||
| Certifications |
FCC CFR 47 Part 15 IEC 62368-1 |
||||
| IP Rating | IP66 IK10 |
||||
| Power | DC12V±25%,PoE (IEEE 802.3af) | ||||
| Dimensions (Φ × H) | Φ149 × 55 mm (Φ5.9" × 2.2") | ||||
| Weight | 524g | ||||
Manuals & Technical Documents
Drivers & Software
Illumivue for MAC iOS v.2Illumivue for Windows 11Illumivue for Windows 10Illumivue Savant Profiles 4.3Illumivue Control4 DriverIllumivue Config for Windows version 2Product Sheet
Download |
ILLUMIVUE PROTECT can directly access video surveillance products through the network to meet your needs of viewing live events on your mobile phone, controlling the pylon, playing back videos, pushing alarms, managing cloud devices, etc. |
|---|---|
  |
 |
ILLUMIVUE TECH is a professional mobile AIoT application for service providers, which can be downloaded and installed free of charge in the mobile app store, and can achieve project management, installation and debugging, remote configuration, operation and maintenance management, video viewing, and PFO control on the mobile terminal. |
|---|---|
| |
 |
ILLUMIVUE (Legacy) App is a mobile surveillance client app. You can access Illumivue surveillance products through network and view live or playback video, receive alarms and manage P2P devices using your mobile phone. |
|---|---|
| |
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
National Defense Authorization Act (NDAA)
The National Defense Authorization Act (NDAA), particularly Section 889, has significant implications for the surveillance industry, especially concerning the procurement of video surveillance equipment. Section 889 prohibits U.S. federal agencies and their contractors from purchasing or using telecommunications and video surveillance equipment from certain manufacturers due to national security concerns.
As security integrators operating in the public sector and government markets, it’s critical to partner with brands that meet U.S. regulatory compliance. Illumivue is fully NDAA-approved, meaning our cameras, recorders, and associated components comply with the National Defense Authorization Act’s requirements that restrict use of certain foreign-made surveillance equipment. This gives you confidence when proposing Illumivue to municipalities, schools, and other agencies that must comply with these standards. Beyond compliance, Illumivue products deliver advanced capabilities—such as full-color night imaging (NightColor), dual-illumination modes (NightLight), intelligent analytics (line crossing, auto tracking, object counting), and plug-and-play setup—that make them a compelling solution both technically and contractually.
